SoliValve®100 technology

The SoliValve®100 is the latest Cone Valve innovation from Visval.

Based on the same principle as its big brother, it allows for the first time fully automatic and contained (OEB5) handling of solids in Pouches, Charge bags, Charge bottles and small drums/container/hoppers (1L to 700L) thank to a universal passive valve of ø 100 mm. Such containers are used for active ingredients like HPAPIs, APIs, Food Additives, Enzymes, Pigments, Metal powders etc. within all major process industries.

The aperture of the SoliValve®100 is controlled by a highly accurate step motor and a play-free ball screw, allowing opening increments down to 0.1 mm.

This exceptional positioning provides incredible dosing accuracy for a wide range of weights, starting at a few grams to hundreds of kilos. With adequate resolution of the scale, the SoliValve®100 can reach a dosing accuracy of +/- 1g.

The containment level of the SoliValve®100 system has been tested and validated for OEB5 (<1µg/m3) applications by an independent institute (SMEPAC test).



Test trials with your powder welcomed!

Visval offers to customers from all over the world a fully comprehensive test lab to conduct discharge & dosing tests. Upon request, we can deliver the SoliValve® to your site in order to conduct the tests. We believe that there is no better way to convince a customer than when he can see the system working from his own eyes.

Contact us for a test trial with your powder!
